Marx HDMI matrix switch 4x2

Name: Marx HDMI matrix switch 4x2
Brand: JAYSHREE ELECTRONICS
Price: 7500 INR
Availability: InStock

Price 7500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Marx HDMI matrix switch 4x2 Specification

Processing
Electronics Assembly

Surface Treatment
Powder Coating

Installation Guideline
Plug and play, connect HDMI cables to corresponding ports, power on the device

Input Voltage
100-240V AC, 50/60Hz (Adapter)

Service Period
1 Year Warranty

Finish
Matte

Temperature
0°C to 40°C

Standard
HDMI 1.4 / HDCP 1.4 Compliant

Frequency
50/60 Hz

Usage
Audio Video Signal Switching

Technique
High-speed Digital Switching

Color
Black

Application
Commercial/Industrial/Residential AV Systems

Process
Signal Routing, Video Distribution

Material
Metal Casing

Thickness
Approx. 1.5 mm (casing)

Supply Voltage
DC 5V (via Adapter)

Output Voltage
5V (Output signal via HDMI standard)

Equipment Type
Matrix Switcher

Humidity
10% - 90% RH, non-condensing

Design
4x2 Matrix

Size
Standard Compact

Product Type
HDMI Matrix Switch

Mounting Type
Desktop / Tabletop

Weight
Approx. 350 g

Dimension (L*W*H)
210 x 95 x 25 mm

LED Indicators
Yes, Status Indicators for Input/Output Selection

Power Consumption
<5W

HDMI Versions
1.4 Compatible

Control Mode
Front Panel Buttons, IR Remote

Switching Time
<3 Seconds

Cascade Capability
Supported

Number of Input Ports
4 HDMI Inputs

Supported Audio Format
LPCM, Dolby AC3, DTS 7.1, DSD

Number of Output Ports
2 HDMI Outputs

Max Resolution Supported
Up to 1080p @ 60Hz (Full HD)

Package Includes
Matrix Switcher, IR Remote, Power Adapter, User Manual

About Marx HDMI matrix switch 4x2

Four 4K HDR signal sources can be connected to TWO HD displays or monitors using the HDMI Matrix 4x2 Switch. It also has the ability to extract the HDMI input Audio signal for output via Toslink SPDIF optical fibre or 3.5mm stereo headphone jacks. An IR remote control can be used to operate this 4x2 HDMI matrix. It makes it simple to swap or divide four HDMI devices across two HDMI-compatible monitors or projectors.

Versatile AV Matrix Switching

Effortlessly route any of the four HDMI inputs to either of the two HDMI outputs. The matrix design boosts flexibility, allowing independent or simultaneous viewing experiences across different displays. Perfect for presentations, entertainment centers, or digital signage, the device ensures smooth signal distribution with rapid switching and reliable HDCP 1.4 compliance.

High-Quality Audio and Video Support

Experience vivid Full HD 1080p video and immersive audio with support for LPCM, Dolby AC3, DTS 7.1, and DSD formats. The matrix switcher's high-speed digital processing technology delivers pristine signal integrity for all connected devices, catering to both high-performance commercial installations and demanding home theaters.

User-Friendly Operation and Installation

Enjoy hassle-free setup with plug-and-play functionality. Simply connect your HDMI cables, power on using the adapter, and control inputs/outputs via the front panel or included IR remote. LED indicators clearly display the active ports, simplifying management. The compact metal build is ideal for desktop or tabletop placement.

FAQ's of Marx HDMI matrix switch 4x2:

Q: How do I install and set up the Marx HDMI Matrix Switch 4x2?

A: Installation is straightforward: connect your HDMI input sources and output displays to the corresponding ports, plug in the power adapter, and use the front panel buttons or IR remote to select your desired input-output combination. The device is plug-and-play, requiring no software setup.

Q: What benefits does this matrix switcher provide for multi-display environments?

A: This 4x2 matrix switch lets you display any of the four HDMI sources on either or both of the two outputs independently. It offers flexibility for various applications, such as controlling multiple displays in commercial venues, conference rooms, or home entertainment systems, without the need to frequently reconnect cables.

Q: What audio and video formats does the Marx HDMI Matrix Switch support?

A: The matrix switcher supports Full HD 1080p video at 60Hz and is compatible with LPCM, Dolby AC3, DTS 7.1, and DSD audio formats, ensuring superior AV experiences for diverse signal sources and audio systems.

Q: How can I control the HDMI matrix switch?

A: You can conveniently operate the switch through the included IR remote control or the front panel buttons. LED indicators on the matrix assist in confirming which inputs and outputs are currently active.

Q: Where is this product best suited for use?

A: The Marx HDMI Matrix Switch 4x2 is versatile, suitable for commercial, industrial, and residential AV distribution systems, including conference halls, entertainment setups, and retail environments.

Q: Can the matrix switcher be cascaded for larger systems?

A: Yes, cascade capability is supported, allowing multiple matrix switches to be connected together for expanded multi-source/multi-display configurations in large-scale AV installations.
